3D CONCRETE PRINTER PLANTS
Polygonmachine 3D Concrete Printer Plants represent a new generation of automated construction systems that combine precision batching, intelligent material mixing, and robotic extrusion technology.
These plants are purpose-built for 3D concrete printing, enabling architects, contractors, and research institutions to produce complex geometries, sustainable housing elements, and advanced infrastructure components with high accuracy and repeatability.
Why choose Polygon Machine?
Polygon Machine delivers certified quality (TSE & ISO 9001), global expertise, and durable solutions from 30 m³/h to 240+ m³/h. Polygonmachine is a trusted partner in both compact and large-scale projects.
What batching plant types are available?
Stationary, mobile, and compact plants—plus cement silos, feeders, and dosing units. Every system is customizable to match your space, capacity, and automation needs.
How is long-term support handled?
Polygon Machine ensures fast setup, training, and after-sales service, minimizing downtime. All plants include modern automation and safety features for easy, efficient use.
Technical Specifications
| Parameter | Specification |
|---|
| Production Capacity | 15–60 m³/h |
| Mixer Type | PPX 1000 Planetary Mixer |
| Mixer Volume | 1000 liters (1.0 m³ per batch) |
| Motor Power | 37 kW |
| Aggregate Weighing | 3000 kg |
| Water Weighing | 300 liters |
| Cement Weighing | 500 kg |
| Additive Weighing | 300 liters |
| Accuracy | ±1% per batch |
| Control System | PolySmart™ PLC + HMI Touchscreen |
| Printing Feed System | Screw or Pump-Based Continuous Extrusion |
System Components
1. High-Precision Mixing Unit
At the heart of the 3D printer plant is the Polygonmachine PPX Planetary Mixer, delivering ultra-homogeneous concrete mixes with carefully controlled viscosity and fiber dispersion.
This ensures smooth, layer-by-layer extrusion and perfect interlayer bonding for structural integrity.
2. Material Dosing and Feeding System
Automated cement, sand, water, and additive dosing units ensure consistent mix proportions.
A variable-speed pump or auger feeder supplies the printing head continuously without pulsation or delay.
3. Robotic Printing Gantry or Arm System
Depending on project requirements, Polygonmachine offers multi-axis gantry-type printers for large structures and robotic-arm systems for laboratory or modular 3D printing.
Both systems use precision servo control and path optimization for exact geometry realization.
4. Real-Time Monitoring & Control
All process parameters—including flow rate, pressure, temperature, and moisture—are monitored and adjusted automatically via the PolySmart™ Automation Interface.
The system can import 3D models directly from CAD/CAM software.
5. Additive Management and Fiber Integration
Optional fiber dosing and chemical admixture systems allow customization of mechanical and rheological properties for specialized applications such as high-strength or lightweight printed structures.
Performance
Printing Accuracy: ±0.5 mm
Mixing Homogeneity: >98%
Layer Height Range: 10–40 mm adjustable
Continuous Operation Time: Up to 8 hours
Setup Time: <3 hours
Power Requirement: 380–400 V, 3-phase
Applications
3D Housing Construction: Walls, beams, and architectural panels.
Infrastructure Components: Retaining walls, culverts, and street furniture.
Research & Development: University or laboratory-scale 3D concrete studies.
Custom Architectural Fabrication: Facades and aesthetic elements with parametric design.
Precast and Modular Construction: Integration with Polygonmachine batching systems.
Advantages
Fully integrated mixing-to-printing automation
High precision with consistent rheology control
Environmentally sustainable, low-waste operation
Modular plant design for easy transport and setup
Compatible with eco-friendly cements and recycled aggregates
Seamless connectivity with Polygonmachine batching and dosing units
