Polygonmachine PWF Series Wobbler Feeders
Polygonmachine PWF Series Wobbler Feeders
Polygonmachine PWF Series Wobbler Feeders are designed to handle wet, sticky, and clay-contaminated materials that conventional vibrating feeders struggle to process.
They ensure smooth, clog-free material flow while effectively separating fines from oversize feed before it enters the primary crusher.
Engineered for high-capacity, continuous operation, these feeders are ideal for heavy-duty mining, quarrying, and aggregate applications.
Technical Specifications
| Model | Dimensions (W×L) (mm) | No. of Shafts | Capacity (tph) | Power (kW) | Adjustable Gap (mm) | Weight (kg) |
|---|---|---|---|---|---|---|
| PWF-1035 | 1000×3500 | 5–7 | 200–300 | 22 | 40–150 | 10,800 |
| PWF-1235 | 1200×3500 | 5–7 | 300–400 | 22 | 40–150 | 12,500 |
| PWF-1440 | 1400×4000 | 6–8 | 350–450 | 22 | 40–150 | 14,800 |
| PWF-1640 | 1600×4000 | 6–8 | 400–600 | 22 | 40–150 | 16,900 |
| PWF-1860 | 1800×6000 | 9–10 | 650–1000 | 22 | 40–150 | 20,400 |
Key Features
Self-Cleaning Roller Design:
Unique elliptical rollers continuously rotate against each other, preventing clogging and enabling self-cleaning during operation.
Efficient Fines Separation:
Fine materials fall through adjustable gaps between rollers, reducing crusher wear and increasing plant efficiency.
Heavy-Duty Frame Structure:
Constructed from high-tensile steel with reinforced cross beams for maximum durability under heavy loads.
Adjustable Gap System:
Hydraulic or mechanical adjustment allows quick control of separation size from 40 mm up to 150 mm.
Smooth Material Flow:
Continuous rotation ensures consistent feed, even with wet or sticky materials like clay, limestone, and marl.
Low Maintenance Requirements:
Sealed bearings, centralized lubrication, and easily replaceable wear components ensure long service life and reduced downtime.
Variable Speed Drive:
Equipped with frequency inverter (VFD) for adjusting shaft speed according to feed type and desired output.
High Capacity & Energy Efficiency:
Delivers superior throughput while consuming less power than conventional vibrating or apron feeders.
Performance
-
Feed Size: Up to 1000 mm
-
Material Moisture: Up to 30%
-
Separation Range: 40–150 mm
-
Rotational Speed: 20–60 rpm adjustable
-
Throughput Capacity: Up to 1000 tph
-
Noise Level: <80 dB(A)
-
Operating Angle: 0°–10° adjustable
Applications
-
Limestone & Clay Processing: Pre-screening sticky feed before crushers.
-
Quarrying & Mining: Handling wet overburden, limestone, marl, and shale.
-
Recycling Plants: Feeding demolition debris and mixed materials.
-
Cement Plants: Feeding raw materials into primary crushers with reduced blockages.
-
Aggregate Production: Removing fines before crushing to increase efficiency.
